ReadySeal Traffideck E4 Primer

DESCRIPTION
Traffideck E4 Primer is a formulated 100% solids epoxy primer and sealer for concrete, steel and timber surfaces. Supplied as a kit consisting of Part A Component Traffideck E4 Primer Resin and Part B Component Traffideck E4 Primer Curative.

Surface Preparation
• All surface should be prepared strictly in accordance with the manufacturer’s specification and surface preparation document.

• Cementitious substrate moisture content must not exceed 4% by volume and must be protected against rising damp. Surfaces must be dry and failure to comply with the above may result in failures.

• The temperature of the substrate must be at least 3°C above the current dew point temperature.

• All substrate repairs must be fully cured and compatible with any product that may be subsequently applied. The substrate must be of a load bearing quality.

If there are any doubts about suitability a small trial area should be applied and tested for suitability.

Mixing instructions
Traffideck E4 Primer is supplied in pre-weighed packages. It is essential that all of Part B (the hardener) is added to all of Part A (the resin) and mixed thoroughly in a separate 20 litre mixing vessel using an electric drill and missing paddle as slow speed (300 – 400 rpm) for a minimum of 2 minutes, ensuring a homogeneous streak free mix is achieved. This involves working the paddle around the sides and bottom of the vessel ensuing that no unmixed material remains.

APPLICATION
• Once fully mixed the Traffideck E4 Primer should be applied immediately to the substrate using a flat rubber or foam squeegee, twin-armed roller, brush or airless spray. It must then be back-rolled with a medium nap roller sleeve to fill voids and pores in the substrate. To provide a mechanical key the primer must be fully aggregated with 0.3 – 0.6mm kiln dried crystallised quartz sand immediately after the primer has been back-rolled.

• Once the primer has cured to a tack-free state the excess kiln dried crystallised quartz sand must be removed using a stiff bristled broom or mechanical sweeper followed by vacuuming or compressed air blowing prior to over-coating.

• Extremely porous substrates or substrates susceptible to rising damp/moisture may require a two-coat primer application in order to fully seal the surface, this should be determined by site trial.

• If the surface is extremely rough, porous or textured Traffideck E4 Primer should be applied by roller. Consumption will increase and care must be taken to remove “puddles” of primer before broadcasting the aggregate.

• Extra care must be taken to ensure all substrates are kept dry and the temperature of the substrate must remain at least 3°C above the current dew point temperature whilst curing. Failure to protect the primer from moisture during curing will have a detrimental effect in the adhesion between layers and must therefore be removed.

• The workability of reacting material will be influenced by the substrate and ambient temperature.

• Traffideck E4 Primer should be used at an ambient temperature of 7°C – 35°C, if the temperature falls below 7°C Traffideck E4 Primer should not be used.

• Part A and Part B component temperature should be 15°C – 30°C at the time of processing.

• Under no circumstances should applications be carried out in damp weather conditions or if rain is forecast.

MedO DM6 Drainage Board

DESCRIPTION
Radmat DM6 is a drainage board consisting of a non woven needle punched geotextile filter layer thermally bonded to one side of a 6mm deep HDPE (High Density Polyethylene) cuspated core. DM6 is effectively impermeable one side. The textile filter has a flap extending beyond the core on one edge.

APPLICATION
Unroll over surface overlapping fleece as installing.

Texsa Root Barrier P

DESCRIPTION
Radmat Texsa Root Barrier P is an APP plastomeric bitumen-based waterproofing membrane, with anti-root treatment for blue/ green roofing with non-woven polyester felt reinforcement. Coated with a PE Film on both sides Radmat Texsa Root Barrier P is suitable for green roof, blue roof and protected roof applications.

Radmat Texsa Root Barrier P is a Reinforced Bitumen Membrane Cap Sheet for use in a 2 layer EshaFlex system.

Suitable for all types of roof with a flat or sloped roof construction on new build or refurbishment.

For all applicable roofing systems contact Radmat Building Products.

For a comprehensive NBS J41 specification contact Radmat Building Products

Fire Performance When incorporated in a Radmat green roof, blue roof or protected roof application with either MedO GM20, MedO GM30 or MedO GM40 growing medium at a minimum settled depth of 80mm Broof(t1) to BS EN 13501-5 will be achieved.

Suitable Substrates
Timber, concrete, metal deck.

Certificates
BBA certificate No. 97/3336

APPLICATION
Torch applied to base sheet or suitable surface in accordance with the Radmat specification.
Overlaps must be torched. Side laps minimum 80mm. Head laps minimum 100mm.

Radmat 370 RootSafe Texsa Black Mineral

DESCRIPTION
Radmat 370 RootSafe Texsa Black Mineral is an APP plastomeric bitumen-based waterproofing membrane, with anti-root treatment for blue/green roofing with non-woven polyester felt reinforcement. Coated with a mineral granule topside and PE film underside Radmat 370 RootSafe Texsa Black Mineral is suitable for green roof, blue roof and protected roof applications.

Radmat 370 RootSafe Texsa Black Mineral is a Reinforced Bitumen Membrane Cap Sheet for use in a 2 layer EshaFlex system and as a Protection Sheet in PermaQuik Hot Melt Systems.

Suitable for all types of roof with a flat or sloped roof construction on new build or refurbishment.

Any waterproofing upstands not covered by the green roof substrate should be completed using EshaFlex 370 FireSafe. For all applicable roofing systems contact Radmat Building Products.

For a comprehensive NBS J41 specification contact Radmat Building Products

Fire Performance When incorporated in a Radmat green roof, blue roof or protected roof application* with either MedO GM20, MedO GM30 or MedO GM40 growing medium at a minimum settled depth of 80mm Broof(t1) to BS EN 13501-5 will be achieved.

Suitable Substrates
Timber, concrete, metal deck.

Certificates
BBA certificate No. 15/5282

APPLICATION
Torch applied to base sheet or suitable surface in accordance with the Radmat specification. Overlaps must be torched. Side laps minimum 80mm. Head laps minimum 100mm.
